HCA - Freight Brown - Pack 1
HCA - Freight Brown - Pack 1
Out of stock
Detailed Description
Detailed Description
HCA Early Canopy
HOP 32 AB
-
Freight Brown / Bauxite
-
1965-1985
- Wagon Numbers
- 351223
- 351564
- 350001
Photographed model is a decorated sample, and may not be fully indicative of the final model.
Highly-detailed OO gauge model, 1:76.2 scale on 16.5mm track
* Minimum Radius 438mm (2nd Radius Set-track)
* Weight 40g minimum
* Die-cast chassis for ideal weight
* Detailed interior with rivets, framing, strapping and accurately profiled door 'horns'
* RP25-110 profile OO gauge wheels with separate brake blocks in line with tread
* Sprung metal buffers and dummy instanter couplings
* Super fine plastic parts, incl. air pipes, lamp irons, safety catches, clasp and disc brakes, hopper door operating equipment, etc.
* Etched metal details, incl. brake lever, chassis plates, etc.
* Removable, Kinetic NEM coupler mounts at correct height with mini-tension-lock couplers provided with scale Instanters included
Numerous individual differences between wagon types
* Three body styles: as built, rebodied and CDA
* Two styles of hopper door: 'X' pattern on coal variants and 'straight beam' pattern on CDA
* Original canopy and later 'aerodynamic' canopy styles where appropriate
* Two style of door operating equipment covers, with some later styles featuring 'mix and match' versions!
* Two styles of sprung buffer: Oleo (coal variants) and heavy duty (CDA)
* Three different chassis frame variants for HAA, HDA and CDA versions
* Multiple bufferbeam brake pipe configurations
* Three different wheel variants: bolted disc brake, plain disc brake and standard (clasp brake)
* HBA/HDA feature correct modifications to brake disc caliper operating equipment, additional larger air cylinder, empty/loaded changeover levers and above solebar mounted brake distributor
* CDA correctly features large end air cylinder and above solebar mounted brake distributor, end ventilator boxes, highly detailed roof with textured canvas cover and chassis mounted operating handles
Specification
Specification
Lighting and DCC
Lighting and DCC
Common Features
Common Features
Customer Reviews
Superb model engineering - accurately researched and executed.
Had a credit note so used it to buy 2 packs(not too worried about duplicate running numbers) they are a lot more expensive than I normally buy even with the discount but generally do look a lot better, if I had a complaint the hoppers look very plastic in there natural state and weathering needs to be applied.
This was a bit of an impulse buy, but glad I did not resist. As expected an excellent model and representing real value for money. I now just have to get a loco to pull them…..
good looking well detailed fine running models completes my rake of mgr wagons
Amazing detail. Runs well and good value.
The team behind the scenes at Accurascale deserve high acclaim for this and other variants of the MGR coal wagons - truly outstanding and a rake of 21 wagons with Class 60 or 56 motive power would be awesome. When's the next production run?
Very well designed and detailed
As always, excellent detailed product, good runners, brass bearings really help. Thought I would have to change the wheels, because of their size, but no.. coupling hight perfect with other different accurascale hoppers. Keep up the good work.
I have bought a few packs of the HCA canopy fitted MGRs to suit my Scottish lowlands modelling. They are a fantastic model, full of details and capture the character of these wagons perfectly.
Excellent detail and paint finish at a very fair price. Good rolling resistance makes it very suitable for a large rake.
